Hybrid Bias Correction
Values, Distributions, Extremes - with Neural Refinement
Values, Distributions, Extremes - with Neural Refinement
A reproducible Python framework that combines Linear Scaling, Empirical Quantile Mapping with a GPD tail, and a lightweight CNN refinement to correct biases in daily satellite precipitation estimates. Built for tropical regions with sparse gauge networks - tested operationally over Indonesia.
Adjusting values, aligning distributions, preserving extremes - with neural refinement where station density allows.
Python 3.10+ MPL-2.0 v2026.05
What data does it work with?
The framework is designed for three products on a common 0.1 deg daily grid:
| Role | Product | Source | Used for |
|---|---|---|---|
| Satellite (corrected) | IMERG Late Run V07 | NASA GPM | The field being bias-corrected |
| Reference | CPC-UNI (0.5 deg native + regridded to 0.1 deg) | NOAA PSL | Distribution / quantile target for the correction |
| Independent check | BMKG station observations (Indonesia) | National service | Validation only, held out from training |
Other products work too, as long as they follow the same structure: CF-compliant NetCDF, daily timestep, lat/lon grid, mm/day units, with variable names declared in config.yml. See Data Model for the exact conventions and Data Preparation for the workflow of swapping in a different source or region.
What it does
The framework takes the satellite product and a gauge-based reference, and produces a bias-corrected daily field that better matches the reference distribution while preserving the satellite’s spatial detail. Three correction stages are applied in sequence:
- LS - Linear Scaling matches the long-term mean per dekad.
- LSEQM - Empirical Quantile Mapping reshapes the full daily distribution, with a Generalized Pareto Distribution fit to the upper tail to handle extremes.
- LSEQM+DL - A CNN learns the residual spatial pattern and refines the extremes, blended back into LSEQM with a station-density confidence mask so the deep learning correction only takes effect where gauge support justifies it.
Each stage can be evaluated independently against the reference and against an independent set of BMKG weather stations.
Why it exists
Satellite precipitation underestimates light rain, mis-shapes the upper tail, and varies in skill across the seasonal cycle. Pure statistical correction handles the marginal distribution well but ignores spatial structure. Pure deep learning needs training data that does not exist in sparsely gauged regions. This framework keeps the statistical core as a physical floor and adds DL only where it earns its keep.
Key Features
Dekad-Aware Correction
- Parameters fit per 10-day window (36 per year)
- Captures the wet-dry seasonal cycle
- No global parameters that wash out tropical variability
Distribution-Aware
- Gamma fit to the body of the distribution
- Generalized Pareto Distribution for the tail
- 80th-percentile threshold by default (sensitivity caveat documented)
Station-Density Aware
- Gauge-count-driven confidence mask at CPC 0.5 deg resolution
- Gaussian-smoothed, saturating with station count
- DL influence scales with local gauge support
Reproducible
- Single
config.ymldrives every path and parameter - Notebooks call
src/modules (no inline algorithms) - Bali example data ships with the repo for end-to-end testing
Validated
- Continuous Quality Index combining basic, distribution, and temporal scores
- Independent BMKG station validation (held out from training)
- WMO-compliant metrics
Colab-Ready
- Run the full Bali pipeline in a free Colab session
- No CUDA or TensorFlow install pain on the user side
- The same code that ran the Indonesia evaluation runs the tutorial
At a Glance
| Domain | Tropical (operationally tested over Indonesia) |
| Resolution | 0.1 deg, daily |
| Period | 2001 onward (IMERG V07 availability) |
| Reference | CPC-UNI (gauge-based) |
| Satellite | IMERG Late Run V07 |
| Independent check | BMKG weather stations |
| License | MPL-2.0 |
Next steps
- Install the package and reproduce the Bali quickstart
- Open the QA Framework and Station Validation tutorials to see what the framework actually produces
- Explore the Case Studies: the runnable Bali example and the full Indonesia evaluation, including the correlation ceiling diagnostic
- Open the interactive dashboard to explore the Indonesia results directly: staged skill, the correlation ceiling, and the calendar-window recovery
- Read the methodology overview to understand the LSEQM+DL design
- See the Changelog for what’s in v2026.05
- Browse the API reference for module-level documentation
Publication
Companion paper: Istanto, B.; Boer, R.; Santikayasa, I.P. A Modular and Transferable Framework for Enhancing Satellite-Derived Daily Precipitation: Adjusting Values, Aligning Distributions, and Preserving Extremes. Remote Sens. 2026, 18, 2298. https://doi.org/10.3390/rs18142298
How to cite
If you use this framework in a publication, please cite the paper:
Istanto, B.; Boer, R.; Santikayasa, I.P. A Modular and Transferable Framework for Enhancing Satellite-Derived Daily Precipitation: Adjusting Values, Aligning Distributions, and Preserving Extremes. Remote Sens. 2026, 18, 2298. https://doi.org/10.3390/rs18142298
To cite the archived software release:
Istanto, B., Boer, R., & Santikayasa, I. P. (2026). Hybrid Bias Correction: Values, Distributions, Extremes - with Neural Refinement (v2026.05). Zenodo. https://doi.org/10.5281/zenodo.20473508
To cite the bundled full-Indonesia data archive:
Istanto, B., Boer, R., & Santikayasa, I. P. (2026). Hybrid Bias Correction of IMERG Late Run V07 over Indonesia (2001-2025): Input Data, Land-Sea Masks, and Corrected Products (Version 1) [Data set]. Zenodo. https://doi.org/10.5281/zenodo.20287847
Machine-readable metadata is in CITATION.cff; GitHub renders it as a “Cite this repository” button on the repo landing page.
